Hobbywing QuicRun Fusion Pro Elite 2300KV 2-1 FOC Motor

Hobbywing QuicRun Fusion Pro Elite 2300KV 2-1 FOC Motor

N$3,399.68
Sale price  N$3,399.68 Regular price
2 left

Achieve the ultimate stealth and performance upgrade for your 1/10 scale crawler with the Hobbywing QuicRun Fusion Pro Elite 2300KV 2-in-1 Brushless FOC System. Redefining space-saving design, the Pro Elite integrates the ESC and motor into a single ultra-short 48.5 mm housing—making it even shorter than standard 540 cans to guarantee a clean, hassle-free installation in tight chassis layouts.

In the Box

(1) QuicRun Fusion Pro Elite 2-in-1 FOC System (with factory-installed XT60 plug)
(1) Product Manual & Decal Sheet
(1) Heatshrink kit, double-sided tape, and zip ties

More Information

Driven by advanced Field-Oriented Control (FOC) technology, this system delivers near-silent operation, silky-smooth low-speed startup, and intelligent closed-loop speed control that automatically feeds extra torque over obstacles or holds your rig securely on steep descents. With 2S to 4S LiPo support, a high-power adjustable BEC, and real-time parameter tuning straight from your transmitter via an auxiliary channel, the Fusion Pro Elite is the pinnacle of scale crawling performance.

Diligent pairing with a 3S or 4S LiPo makes the Fusion Pro Elite an absolute game-changer for scale rigs needing low-end finesse combined with high-voltage wheel-speed.

Features

Ultra-Compact 2-in-1 Design: Measures just 48.5 mm in total length, fitting nearly all 1/10 scale crawler chassis on the market while eliminating messy wiring. FOC (Field-Oriented Control) Technology: Provides exceptional low-speed torque, buttery-smooth linear throttle response, and completely silent motor operation. Intelligent Closed-Loop Torque Control: Automatically matches motor RPM and increases output torque when hitting resistance, maintaining stable vehicle speeds on climbs and descents. 2S to 4S LiPo Power Support: Built to handle up to 4S LiPo inputs, giving you massive headroom for wheelspeed and power. AUX Real-Time Tuning: Connect the yellow signal wire to an unused receiver channel to tweak parameters (like drag brake force) directly from your radio on the trail. High-Power Adjustable BEC: Built-in switch-mode BEC supporting 6V, 7.4V, or 8.4V output (5A continuous / 150A peak system current) to effortlessly drive high-torque servos and winches. IP67 All-Weather Protection: Completely sealed against water, mud, sand, and snow for worry-free all-terrain bashing.

We will work quickly to ship your order as soon as possible. Once your order has shipped, you will receive an email with further information. Delivery times vary depending on your location.Ultra-Compact 2-in-1 Design: Measures just 48.5 mm in total length, fitting nearly all 1/10 scale crawler chassis on the market while eliminating messy wiring. FOC (Field-Oriented Control) Technology: Provides exceptional low-speed torque, buttery-smooth linear throttle response, and completely silent motor operation. Intelligent Closed-Loop Torque Control: Automatically matches motor RPM and increases output torque when hitting resistance, maintaining stable vehicle speeds on climbs and descents. 2S to 4S LiPo Power Support: Built to handle up to 4S LiPo inputs, giving you massive headroom for wheelspeed and power. AUX Real-Time Tuning: Connect the yellow signal wire to an unused receiver channel to tweak parameters (like drag brake force) directly from your radio on the trail. High-Power Adjustable BEC: Built-in switch-mode BEC supporting 6V, 7.4V, or 8.4V output (5A continuous / 150A peak system current) to effortlessly drive high-torque servos and winches. IP67 All-Weather Protection: Completely sealed against water, mud, sand, and snow for worry-free all-terrain bashing.

Specifications

Application - 1/10 Scale Rock Crawlers and Trail Rigs
Type - Brushless Sensored 2-in-1 Integrated System (FOC)
KV Rating - 2300KV
Continuous / Peak Current - 50A / 150A
LiPo Input - 2-4S LiPo / 6-12 Cell NiMH
BEC Output - 6V / 7.4V / 8.4V Adjustable (Switch-mode: 5A Continuous)
Waterproof Rating - IP67 Weatherproof
Dimensions (Diameter x Length) - 37 mm x 48.5 mm
Shaft Diameter & Length - 3.175 mm (1/8") x 16 mm
Weight - 178.5g (including wires and connectors)
Programming Compatibility - LED Program Box / LCD Pro / LCD G2 Program Boxes (Note: OTA Bluetooth module not supported)
